| Weight |
22 kg. |
| Dimension |
48 x 38 x 28cm |
| Chassis |
Machined Aluminium |
| Colors |
Black, Nickel, Champagne |
| Operating Voltage |
230V 50Hz |
| Power Consumption (Operation / Standby) |
160W / 0.3W |
| Mains Fuse |
2A slow-blow |
| Electron Tube Complement |
One Matched Pair Western Electric 300B, 2x ECC81 |
| Phono MM Sensitivity (10W / 4Ω |
0.75mV |
| Phono MC Sensitivity (10W / 4Ω) |
70μV |
| CD Sensitivity (10W / 4Ω) |
0.27V |
| CD Input Impedance |
20 kOhms |
| Phono MM Input Impedance |
47 kOhms | | 100 pF |
| Phono MC Input Impedance |
1000 kOhms (adjust via Phono Load plugs) |
| SNR MM (10W / 4Ω, input 5mV) |
83 dB(A) |
| SNR MC (10W / 4Ω, input 0.5mV) |
73 dB(A) |
| SNR CD (10W / 4Ω, input 0.5V) |
101 dB(A) |
| CD Frequency Response |
15 Hz - 32 kHz (-3 dB) |
| Phono Frequency Response |
30 Hz - 20 kHz (RIAA within +/- 0.5 dB) |
| Output Power / 4 Ω / THD 10% |
2 x 20 watts |
| Output Power / 4 Ω / THD 5% |
2 x 16 watts |
| Output Power / 4 Ω / THD 3% |
2 x 14 watts |
| Output Power / 8 Ω / THD 10% |
2 x 20 watts |
| Output Power / 8 Ω / THD 5% |
2 x 16 watts |
| Output Power / 8 Ω / THD 3% |
2 x 14 watts |
| BT Standard |
v4.2 |
| BT Codecs |
BC, MP3, AAC, Fastream, APTX |
| BT Sample Rate (adaptive) |
Up to 96kHz / 16-bit |
| BT frequency response |
20 Hz - 20 kHz |
| BT SNR |
96dB |
| |
|
